Single head chop saw (downstroking cutting-off machine) with left loading side, rotation of the cutting head by 45° (to right and left) and manual tilting by 45° about the horizontal axis.
The TKE 340 SD cutting zone comprises a cast-iron horizontal worktable with rigid vertical fence and considerable support area to allow optimum clamping of the workpieces. It is provided with a pair of horizontal clamps which are operated pneumatically in the S version, and manually operated in the M version.
- Carbide-tipped, 400mm ø blade
- Pair of manual or pneumatic horizontal clamps (depending on model)
- Robust cast-iron horizontal work table with vertical fence
- Manual blade operation with mechanical safety interlock
- Local guard for cutting zone, mechanically operated
- Spray-mist lubrication system with oil and water emulsion
| BLADE |
Carbide-tipped blade (mm) |
400 |
| BLADE FEED |
Manual |
| CUTTING ZONE GUARDS |
Local guard, mechanically operated |
| LUBRICATION SYSTEM |
Spray-mist lubrication with water and oil emulsion |
| CLAMPS |
Pair of manual or pneumatic horizontal clamps (depending on model) |
| MOTOR |
Three-phase brake motor, operating time 10 sec. (kW) |
2,2 |
